Using Google Cloud Vertex AI

info

Take-home activity! Do it if you are following along at home. It won't be covered during the hands-on lab.

Google Cloud now offers a series of AI platform services that are built on top of Vertex AI. These services are designed to help you build, deploy, and manage machine learning models.

To create embeddings, they offer several services to convert text, images, or both into embeddings. In our application, we will use the multimodal embedding model to search for books by a description of the cover image.

Create a Google Cloud account

The first step is to create a Google Cloud account. Use the following link to get started with free credits.

Sign Up for a Google Cloud Account

Create a new project

For the welcome screen, create a new project. You can name it whatever you like.

Make sure that you pick an active billing account.

Once the fields are filled out, click the Create button.

Open Cloud Shell

Once your project is created, look for the Activate Cloud Shell button in the top right corner of the screen.

This will open up a terminal-like window in your browser. This is a fully functional terminal that is connected to a virtual machine in the cloud. You can use this terminal to run commands on your virtual machine.

Enable the AI Platform API

You will need to enable the AI Platform API for your project. You can do this by running the following command in your Cloud Shell.

gcloud services enable aiplatform.googleapis.com

Create an authentication file

To authenticate with the AI Platform API, you will need to create a file that contains your application credentials. You can do this by running the following command in your Cloud Shell.

gcloud auth application-default login

Follow the instructions in the terminal to authenticate with your Google Cloud account. Once you have authenticated, you will see a message similar to the following.

Credentials saved to file: [/tmp/tmp.n0HdRFDDv8/application_default_credentials.json]

Save the credentials file to your home directory.

mv /tmp/tmp.n0HdRFDDv8/application_default_credentials.json ~/credentials.json

Create embeddings for some text

Start by creating a request.json file. This file will contain the text that you want to convert into embeddings. Run the following command in the Cloud Shell to create this file.

echo '{
  "instances": [
    {
      "text": "picture of a cat"
    }
  ]
}' >> request.json

Now run the following curl command to get the embeddings for the text.

curl -X POST \
    -H "Authorization: Bearer $(gcloud auth print-access-token)" \
    -H "Content-Type: application/json; charset=utf-8" \
    -d @request.json \
    "https://us-central1-aiplatform.googleapis.com/v1/projects/$PROJECT_ID/locations/us-central1/publishers/google/models/multimodalembedding@001:predict"

Make sure to change the $PROJECT_ID variable to your project ID.

You will receive a response similar to:

{
  "predictions": [
    {
      "textEmbedding": [
        -0.00566103263,
        0.0202014241,
        -0.00677233562,
        0.0180264488,
        0.0265100803,
         ...
        0.00116232142,
        0.0134601779,
        -0.00257002981
      ]
    }
  ],
  "deployedModelId": "5595742328217141248"
}

You will notice that the textEmbeddings fields contain an array of 1408 numbers. These are the embeddings for the text that you provided.

Create embeddings for the books

To create the embeddings for the books in your collection, run this curl command for each book. This process is somewhat time-consuming, so we've already created them for you.

You can find the 1408 dimensions vector in the embeddings field of the new books collection you imported.

Because we already have the vectors for the books, we can use them with Vector Search.

Querying with vectors

To query the data, Vector Search will need to calculate the distance between the query vector and the vectors of the documents in the collection.

To do so, you will need to vectorize your query. You can use the same function to vectorize your query, as well.

In the library application, we've created a function that will vectorize your query for you. You can find it in the server/embeddings/googleVertex.mjs file.

import aiplatform from '@google-cloud/aiplatform';

const project = process.env.PROJECT_ID;
const location = process.env.PROJECT_LOCATION;

const {PredictionServiceClient} = aiplatform.v1;
const {helpers} = aiplatform;
const predictionServiceClient = new PredictionServiceClient({
    apiEndpoint: 'us-central1-aiplatform.googleapis.com'
});

const getTermEmbeddings = async (text) => {
  const publisher = "google";
  const model = 'multimodalembedding@001';

  // Configure the parent resource
  const endpoint = `projects/${project}/locations/${location}/publishers/${publisher}/models/${model}`;

  const instance = { text };
  const instanceValue = helpers.toValue(instance);
  const instances = [instanceValue];

  const request = {
    endpoint,
    instances
  };

  // Predict request
  const [response] = await predictionServiceClient.predict(request);
  const embeddings = response.predictions[0].structValue.fields.textEmbedding.listValue.values.map(e => e.numberValue);

  return embeddings;
};

export default getTermEmbeddings;

Configuring the application

In your server/.env file, you'll find a few variables that you can use to configure the application.

The first one is EMBEDDINGS_SOURCE. It tells the application where to get the embeddings from. You can set it to googleVertex.

Then, set the EMBEDDING_KEY to your credentials.json file.

Finally, set the PROJECT_ID and PROJECT_LOCATION to the values for your project.

EMBEDDINGS_SOURCE=googleVertex
EMBEDDING_KEY="./credentials.json"
PROJECT_ID=projectphoenix-verteximage
PROJECT_LOCATION=us-central1

Your application now has a getTermEmbeddings function that will return the embeddings for a given text. You can see the details of this file in the server/src/embeddings/googleVertex.js file.
